If you have any comments, please drop me your comment. Please make sure that you open the port before you are tightening. The table on page 136 will help you with data selecting, and config Sting subset at offset and length. You can specify what is the value that you would like to get by using "String subset" in LabVIEW and you can also adjust the offset and length of string to get your wanted value.

LabVIEW code for access and get a worked result.

In this example, I also attached the LabVIEW project that inclued by VIs following the detalied below: After we get a talked-back message, we can send a command to close the protocol. While the port is open we can send commands to communicate with the controller. Referred to an attached document, we need to open the serial port for communication first(Once we send a message to open the port will be opening only 15 seconds for your access) which means you need to send a command to access within 15 seconds.

Serial ASCII protocol with 3964R handshake.

The way to communicate with this controller by using Serial communication is 2 kinds of serial protocol. I found one document that guild to communicate with Atlas Copco controller you can find more detailed as an attached document.

Since I am trying to get detailed tightening results to logging into LabVIEW. LabVIEW communication with Atlas Copco controller by Using Serial Communication referring open Atlas's protocol.
